| code | Prod. code | Description | Compat. | Modif. | Qty | Notes | Components | Colour | Reman. |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 46437457 | SUPPORT |
|
01 | |||||
| 2 | 5937301 | PLANE WASHER |
|
02 | |||||
| 3 | 13213034 | SCREW |
|
04 | |||||
| 4 | 46523199 | REINFORCEMENT |
|
01 | |||||
| 5 | 13213034 | SCREW |
|
04 | |||||
| 6 | 7633972 | BUSH |
|
01 | |||||
| 7 | 15503821 | NUT |
|
01 | |||||
| 8 | 14496721 | PLANE WASHER 12X24 |
|
01 | |||||
| 9 | 11190774 | LOCK WASHER |
|
02 | |||||
| 10 | 16240424 | SCREW 12X1,25X55 |
|
01 | |||||
| 11 | 16240621 | SCREW 12X1,25X65 |
|
01 | |||||
| 12 | 16240821 | SCREW 12X1,25X75 |
|
01 | |||||
| 13 | 51709070 | PAD |
|
01 | |||||
| 14 | 46460891 | SCREW |
|
02 | |||||
| 15 | 5937301 | PLANE WASHER |
|
02 | |||||
| 16 | 11198371 | LOCK WASHER |
|
01 | |||||
| 17 | 46529259 | SCREW |
|
01 | |||||
| 18 | 46540881 | SCREW |
|
02 | |||||
| 19 | 46523938 | PAD |
|
01 | |||||
| 20 | 15541124 | SCREW M12X1,25X65 |
|
01 | |||||
| 21 | 7736111 | CLIP |
|
01 |
